Frp honeycomb sandwich board floor
good rigidity, waterproof and antisilp frp honeycomb sandwich floor, max THK: 200mm
dimension customized to client.
good rigidity, waterproof and antisilp frp honeycomb sandwich floor, max THK: 200mm
dimension customized to client.
Our frp honeycomb sandwich panel /plate/board are wildly
used for refrigerated truck, container house floor,
swimming pool, water entertainment park building , small pier etc.
We add steel reinforce inside for larger size, also edging if client ask.
Flat surface is available for van flooring
common size 2000*5000*30mm or to order
max THK: 200mm
dimension customized to client.
color/surface pattern above 200sqms could make to order but longer leading time
| PP honeycomb with Non-woven surface | |||
| Cell size | 8mm | 10mm | 12mm |
| Thickness | 5mm-1000mm | ||
| Max length | 1220*2440mm or Customize | ||
| Max width | |||
| Tolerances | ±0.4mm | ||
| Density | 80Kg/m³ | 75Kg/m³ | 70Kg/m³ |
| Compressive strength | GB/T1453 1.5-2 | ||
| Shear strength | 0.5Mpa | ||
| Temperature range | From - 15℃ to + 80℃ | ||
| Flammability | B2 | ||
| Sound reduction Factor 50-4.000HZ | 22db | ||
| Color | White | ||
